FLOODED LINE SERIES
| DEEP-CYCLE FLOODED BATTERIES – with T2 TECHNOLOGY™ | |||||||||||
| TYPE | Vdc | Cap.-C5 | Cap.-C20 | Cap.-C100 | terminal | L*W*Hmm | WEIGHT | pallet | Datasheet | ||
| T105-ELPT | GC2 | 6 V | 185 Ah | 225 Ah | 250 Ah | ELPT | 262*181*281 | 28 kg | 48 | Download | |
| T105-EUT | GC2 | 6 V | 185 Ah | 225 Ah | 250 Ah | EUT | 262*181*281 | 28 kg | 48 | Download | |
| T105+ | GC2 | 6 V | 185 Ah | 225 Ah | 250 Ah | ELPT | 262*181*281 | 28 kg | 48 | Download | |
| T125 | GC2 | 6 V | 195 Ah | 240 Ah | 266 Ah | 1,2,3,4 | 262*181*281 | 30 kg | 48 | Download | |
| T145 | GC2H | 6 V | 215 Ah | 260 Ah | 287 Ah | ELPT | 262*181*302 | 33 kg | 45 | Download | |
| T145+ | GC2H | 6 V | 215 Ah | 260 Ah | 287 Ah | 1,2,3 | 262*181*302 | 33 kg | 45 | Download | |
| TE35 | DIN | 6 V | 200 Ah | 245 Ah | 271 Ah | 8 | 244*191*269 | 31 kg | 48 | Download | |
| J250P | 901 | 6 V | 215 Ah | 250 Ah | 278 Ah | 6 | 176*176*293 | 33 kg | 42 | Download | |
| J305E-AC | 902 | 6 V | 250 Ah | 305 Ah | 339 Ah | 7 | 312*174*265 | 38 kg | 30 | Download | |
| J305G-AC | 902 | 6 V | 258 Ah | 315 Ah | 350 Ah | 7 | 312*174*366 | 40 kg | 30 | Download | |
| J305P-AC | 902 | 6 V | 271 Ah | 330 Ah | 367 Ah | 6 | 296*176*366 | 44 kg | 30 | Download | |
| J305H-AC | 902 | 6 V | 295 Ah | 360 Ah | 400 Ah | 6 | 296*176*366 | 45 kg | 30 | Download | |
| L16E-AC | 903 | 6 V | 303 Ah | 370 Ah | 411 Ah | 7 | 311*174*417 | 45 kg | 28 | Download | |
| L16G-AC | 903 | 6 V | 320 Ah | 390 Ah | 433 Ah | 7 | 311*174*417 | 47 kg | 28 | Download | |
| L16P-AC-DT | 903 | 6 V | 344 Ah | 420 Ah | 467 Ah | DT | 296*176*425 | 52 kg | 28 | Download | |
| L16P-AC-UT | 903 | 6 V | 344 Ah | 420 Ah | 467 Ah | UT | 296*176*425 | 52 kg | 28 | ||
| L16H-AC | 903 | 6 V | 357 Ah | 435 Ah | 483 Ah | 6 | 296*176*425 | 57 kg | 26 | Download | |
| T875 | GC8 | 8 V | 145 Ah | 170 Ah | 189 Ah | ELPT | 259*179*283 | 29 kg | 48 | Download | |
| T890 | GC8 | 8 V | 155 Ah | 190 Ah | 211 Ah | ELPT | 259*179*283 | 31 kg | 48 | Download | |
| T1275 | N/A | 12 V | 120 Ah | 150 Ah | 166 Ah | ELPT | 327*178*276 | 37 kg | 36 | Download | |
| T1275+ | N/A | 12 V | 120 Ah | 150 Ah | 166 Ah | 1 | 327*178*276 | 37 kg | 36 | Download | |
| J150+ | N/A | 12 V | 120 Ah | 150 Ah | 166 Ah | 1,2,3 | 351*178*276 | 38 kg | 36 | Download | |
| J185E-AC | 921 | 12 V | 144 Ah | 175 Ah | 194 Ah | 7, 9 | 394*175*386 | 46 kg | 24 | Download | |
| J185G-AC | 921 | 12 V | 152 Ah | 185 Ah | 205 Ah | 7, 9 | 394*175*386 | 48 kg | 24 | Download | |
| J185P-AC | 921 | 12 V | 168 Ah | 205 Ah | 226 Ah | 6 | 380*176*374 | 52 kg | 24 | Download | |
| J185HG-AC | 921 | 12 V | 185 Ah | 225 Ah | 249 Ah | 7 | 394*175*372 | 56 kg | Download | ||
| 24TMX | 24 | 12 V | 70 Ah | 85 Ah | 94 Ah | 5,9 | 277*168*235 | 21 kg | 54 | Download | |
| 27TMX | 27 | 12 V | 85 Ah | 105 Ah | 117 Ah | 5,9 | 323*168*235 | 25 kg | 54 | Download | |
| 27TMH | 27 | 12 V | 95 Ah | 115 Ah | 128 Ah | 5,7,8,9 | 323*468*235 | 28 kg | 42 | Download | |
| 30XHS | 30H | 12 V | 105 Ah | 130 Ah | 144 Ah | 5,7,8,9 | 355*171*256 | 30 kg | 36 | Download | |
| 31XHS | 30H | 12 V | 105 Ah | 130 Ah | 144 Ah | 11 | 239*171*243 | 30 kg | 36 | Download | |
GEL LINE SERIES
| DEEP-CYCLE GEL BATTERIES | |||||||||||
| TYPE | Vdc | Cap.-C5 | Cap.-C20 | Cap.-C100 | terminal | L*W*Hmm | WEIGHT | pallet | Datasheet | ||
| 6V-GEL | GC2 | 6 V | 154 Ah | 189 Ah | 198 Ah | 6 | 260*180*275 | 31 kg | 32 | Download | |
| TE35-GEL | DIN | 6 V | 180 Ah | 210 Ah | 220 Ah | 8 | 244*190*272 | 31 kg | 45 | Download | |
| 24-GEL | 24 | 12 V | 66 Ah | 77 Ah | 85 Ah | 6,7 | 277*168*235 | 24 kg | 36 | Download | |
| 27-GEL | 27 | 12 V | 76 Ah | 91 Ah | 100 Ah | 7 | 323*162*235 | 28 kg | 28 | Download | |
| 31-GEL | 31 | 12 V | 85 Ah | 102 Ah | 108 Ah | 7 | 329*173*245 | 60 kg | 24 | Download | |
| 5SHP-GEL | DIN | 12 V | 110 Ah | 125 Ah | 137 Ah | 8 | 344*171*279 | 39 kg | 33 | Download | |
| 8D-GEL | 8D | 12 V | 188 Ah | 225 Ah | 265 Ah | 5 | 526*278*275 | 73 kg | 12 | Download | |
AGM LINE SERIES
| RELIANT DC AGM | |||||||||||
| TYPE | Vdc | Ah-C5 | Cap.-C20 | Cap.-C100 | terminal | L*W*Hmm | WEIGHT | pallet | Datasheet | ||
| T105-AGM | 6 V | 171 Ah | 217 Ah | 230 Ah | M8 | 262*179*273 | 31 kg | 48 | Download | ||
| J305-AGM | 6 V | 250 Ah | 310 Ah | 329 Ah | DT | 296*176*355 | 44 kg | 30 | Download | ||
| L16-AGM | 6 V | 290 Ah | 370 Ah | 392 Ah | DT | 296*176*414 | 52 kg | 28 | Download | ||
| T875-AGM | 8 V | 130 Ah | 160 Ah | 170 Ah | M8 | 262*179*273 | 31 kg | 48 | Download | ||
| J185-AGM | 12 V | 157 Ah | 200 Ah | 212 Ah | DT | 380*176*357 | 54 kg | 24 | Download | ||
| U1-AGM | 12 V | 29 Ah | 33 Ah | 34 Ah | IT | 207*132*174 | 12 kg | 64 | Download | ||
| 24-AGM | 12 V | 67 Ah | 76 Ah | 84 Ah | DT | 274*174*220 | 24 kg | 54 | Download | ||
| 27-AGM | 12 V | 77 Ah | 89 Ah | 99 Ah | DT | 318*174*221 | 29 kg | 42 | Download | ||
| 31-AGM | 12 V | 82 Ah | 100 Ah | 111 Ah | DT | 341*174*233 | 31 kg | 36 | Download | ||
SILVER LINE SERIES
| SILVER DEEP CYCLE FLOODED | |||||||||||
| TYPE | Vdc | Ah-C10 | Cap.-C20 | Cap.-C100 | terminal | L*W*Hmm | WEIGHT | pallet | Datasheet | ||
| S-105 | 6 v | 193 Ah | 215 Ah | 232 Ah | ELPT | 262*181*273 | 26 kg | 32 | Download | ||
| S-305 | 6 V | 271 Ah | 295 Ah | 328 Ah | EUTR | 314*174*366 | 38 kg | 30 | Download | ||
| S-16 | 6 V | 333 Ah | 362 Ah | 402 Ah | EUTR | 313*174*417 | 45 kg | 28 | Download | ||
| S-875 | 8 V | 147 Ah | 165 Ah | 176 Ah | ELPT | 259*181*272 | 28 kg | 32 | Download | ||
| S-1275 | 12 V | 126 Ah | 145 Ah | 155 Ah | ELPT | 329*181*275 | 28 kg | 24 | Download | ||
AES SERIES
| AES.DEEP.CYCLE.AGM | |||||||||||
| TYPE | Vdc | Ah-C5 | Ah-C20 | Ah-C100 | terminal | Lmm | Wmm | Hmm | kg | Datasheet | |
| T105-AES | 6 | 163 | 202 | 225 | M8 | 262 | 179 | 273 | 32 | Download | |
| J305-AES | 6 | 250 | 298 | 313 | M8 | 296 | 176 | 358 | 45 | Download | |
| L16-AES | 6 | 290 | 333 | 392 | M8 | 296 | 176 | 417 | 55 | Download | |
| T875-AES | 8 | 130 | 157 | 169 | M8 | 262 | 179 | 273 | 33 | Download | |
| J185-AES | 12 | 149 | 171 | 212 | M8 | 380 | 176 | 367 | 57 | Download | |
| 24-AES | 12 | 67 | 76 | 84 | DT | 274 | 174 | 219 | 24 | Download | |
| 27-AES | 12 | 77 | 89 | 99 | DT | 306 | 174 | 237 | 29 | Download | |
| 31-AES | 12 | 82 | 100 | 111 | M8 | 325 | 173 | 238 | 31 | Download | |
| 31-AES-OVERDRIVE | 12 | 84 | 102 | 112 | M8 | 325 | 173 | 240 | 30 | Download | |
| T1275-AES | 12 | 95 | 124 | 141 | M8 | 329 | 179 | 278 | 39 | Download | |
HYDROLINK WATERVULSYSTEEM
| HYDROLINK WATERINGSYSTEMS | ||||||||
| TYPE | Datasheet | |||||||
| HYDRO-HL-U24V-1 | Hydro-link 24V system for 6V en 12V Trojan batteries | Download | ||||||
| HYDRO-HL-U36V-01 | Hydro-link 36V system for 6V en 12V Trojan batteries | Download | ||||||
| HYDRO-HL-U48V-01 | Hydro-link 48V system for 8V Trojan batteries | Download | ||||||
| HYDRO-HL-U48V-3 | Hydro-link 48V system for 6V en 12V Trojan batteries | Download | ||||||
| HYDRO-HL-U36V-01 | Hydro-link 36V system for 6V en 12V Trojan batteries | Download | ||||||
D O W N L O A D
Trojan Deep Cycle Flooded folder
PDF (387 KB)
engl.
